A3 UV DTF PRINTER(30CM PRINTING WIDTH)

No.A3 UV DTF
  • The crystal label is a new form of self-adhesive sticker without a plate-making print, there is a picture can be printed, can be personalized small batch production, no color restrictions, that is, out of use, visual effect is more three-dimensional and beautiful.
  • Tear the film to leave pictures and texts, rich colors, waterproof and scratch resistant, three-dimensional luster, high temperature resistance and freeze resistance, and the longer the pasting time, the more tired.
  • A3 UV DTF PRINTER(30CM PRINTING WIDTH)
  • A3 UV DTF PRINTER(30CM PRINTING WIDTH)
  • A3 UV DTF PRINTER(30CM PRINTING WIDTH)
  • A3 UV DTF PRINTER(30CM PRINTING WIDTH)
  • A3 UV DTF PRINTER(30CM PRINTING WIDTH)
  • A3 UV DTF PRINTER(30CM PRINTING WIDTH)

SPECIFICATION

  • Print Head Type: F1080-A1
  • Print Head Number: 2pcs
  • Print Head Width: 300mm
  • Print Head Maintenance: Anti-clogging flash spray & auto moisture retention
  • Printing Speed: Draft mode--2.4㎡/h, Production mode--1.6㎡/h, Quality mode--1㎡/h
  • Ink Type: Crystal label specialty ink
  • Ink Colors: C/M/Y/K/W/V + Foil varnish
  • Cartridge Capacity: 250ml/color
  • Curing System: Air cooling + LED UV Iamp
  • Coated Flim Roller: High-temperature-supported hot stamping rubber roller
  • Coated Moving Rod: Controls the balance of film coating paper feeding
  • Printing Medium: AB crystal label specialty materials, etc.
  • Media Thickness: 1-3mm
  • Max Roll Weight: ≤40kg
  • Rewinding System: Standard
  • Unwinding System: Standard
  • Operating System: Win 10 / Win 11
  • Operation Language: Chinese / English
  • Print Interface: Net interface
  • RIP Software: Maintop size
  • Temperature: Temperature--20-28℃, Humidity--38-65C
  • Machine Dimensions: 970x870x650mm (LxWxH)
  • Machine Weight: 80kg
  • Package Dimensions: 1020x830x560mm (LxWxH)
  • Computer Configuration Requirements:
    • Win7/10 64-bit (Clean OS),
    • Win10 must disable driver signature
    • CPU:i5-6500+
    • RAM: 16GB+
    • C disk:250G or more (solid state drive recommended)
